Overview
Audiometer KAU-A100 is a high-precision two channel diagnostic practical screening instrument to examine hearing acuity. Digital signal processing enables high quality masking and refractivity. Alphanumeric trans-reflective LCD screen displays sound output intensity, frequency and test information for visible results.
Features
Wide intensity range
AC up to 250 Hz – 8K Hz
BC up to 250 Hz – 6K Hz
Flexible for clinical and portable use
Special output (SF) [Optional]
Masking for both AC and BC
Built-in microphone for easy communication with subjects
specifications
| Type |
Two-channel for independent outputs |
||||||||||||||||||||||||||||||||||||
| Test Signal |
Pure tone, Pulse tone, Warble tone, Narrowband noise |
||||||||||||||||||||||||||||||||||||
| Output |
TDH 39 Air conduction headset(L/R), B71 Bone conduction headset(L/R), Free Sound field |
||||||||||||||||||||||||||||||||||||
| Input |
Tone and Speech |
||||||||||||||||||||||||||||||||||||
| Attenuation level |
-10 dB ~ 120 dB |
||||||||||||||||||||||||||||||||||||
| Test Frequencies |
11 standard frequency |
||||||||||||||||||||||||||||||||||||
| Test Frequencies Range |
|
||||||||||||||||||||||||||||||||||||
| Patient Response |
hand switches |
||||||||||||||||||||||||||||||||||||
| Microphone |
Built-in microphone (0-20 intensity levels, adjustable) |
||||||||||||||||||||||||||||||||||||
| Standards and Compliance |
EN 60601-1, level 1 class B EN 60601-1-2 EN 60601-1-4 EN60645-1 EN60645-2 EN60645-4 ANSI S3.6-1996 |
||||||||||||||||||||||||||||||||||||
| Distortion |
Air conduction: < 2.5% ; Bone conduction: < 5% |
||||||||||||||||||||||||||||||||||||
| Warm-up Time |
Less than 10 minutes |
||||||||||||||||||||||||||||||||||||
| Connectivity |
USB 2.0 data interface |
||||||||||||||||||||||||||||||||||||
| Report format size |
A4 or B5 format report |
||||||||||||||||||||||||||||||||||||
| Calibration |
Calibrates multiple types of earphone at the same time |
||||||||||||||||||||||||||||||||||||
| Masking |
Pure tone masking ; Ipsilateral masking |
||||||||||||||||||||||||||||||||||||
| Power Supply |
100V / 50 Hz to 240V / 60 Hz |
||||||||||||||||||||||||||||||||||||
| Power Consumption |
60 VA |
||||||||||||||||||||||||||||||||||||
| Dimensions |
450 x 300 x 110 mm |
||||||||||||||||||||||||||||||||||||
| Weight |
2.4 Kgs |
application
Used in ENT hospitals, research communities, rehabilitation centre and deaf training centres for clinical audiometry to test conductive hearing mechanisms.
